Zielgruppe LADY, MAN
Kategorie MANN
Rahmen ALLOY 6061 D.B., 120mm TRAVEL, 27.5"+
Gabel MANITOU MACHETE 27.5" PLUS, TS AIR SPRING, 120mm TRAVEL, TAPERED, 15X110mm AXLE, HYDRAULIC DAMPING
Vorbau LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8", ANGLE:6°
Steuersatz FSA NO. 57, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8mm TOP COVER
Lenker LEVELNINE Race, 720mm, 9° ANGLE, 15mm RISE, 31.8mm
Schaltwerk SHIMANO XT RD-M781 GS SHADOW DESIGN, TOP NORMAL, 10-SPEED
Umwerfer SHIMANO DEORE FD-M6020D, DIRECT MOUNT, SIDE SWING
Schalthebel SHIMANO DEORE SL-M610, WITH OPTICAL GEAR DISPLAY
Bremsen SHIMANO BR-M395, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:203mm, R:180mm ROTORS
Bremshebel SHIMANO BL-M396
Kurbelgarnitur FSA CK745/ISIS, BOOST, 38-28 TEETH
Sattelstütze LEVELNINE Race, 31.6x350mm
Sattel SELLE ROYAL RAMPAGE
Felgen ALEXRIMS XM-35, 32 HOLES, INNER WIDTH 35mm, 27.5"
Nabe vorne SHIMANO DEORE HB-M618-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Nabe hinten SHIMANO FH-M618-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Kette KMC X11 ET EPT, e-Bike, 3x durability
Kassette SHIMANO CS-HG500-10, 11-42 TEETH, 10-SPEED
Reifen SCHWALBE NOBBY NIC PERFORMANCE LINE, 27.5x2.8"
Motor YAMAHA PW-X series, 250 WATT
Batterie YAMAHA LIMN 37.0V, 13.5Ah, 500Wh
Reichweite MAX. 125km
Nettogewicht in kg 22.7
Gänge 20-SPEED
Rahmengeometrie
i-RIDER HD
Federweg Gabel 120mm
Rahmenmaterial ALUMINIUM
Laufradgrösse 27.5"
Rahmengeometrien HARDTAIL
E-Bike Speed 25 km/h
